PVP X6IP

PVP X6IP is an IP65 outdoor-rated video panel with brilliant SMD 2623 LEDs and a pixel pitch of 6.9 mm. With 4,500 NITS, video images stand out even in broad daylight. Flexibility of use is optimized by an advanced die-cast aluminum housing, magnetic modules for quick serviceability, and a blow-through design that has an 8% transparency to increase safety in outdoor applications. The innovative design includes sealable louvers that can be shut to block back light when used indoors.

Features

  • 6.9 mm pixel pitch modular video panel with SMD 2623 LEDs
  • Stainless steel hardware is integrated into each panel for secure interlocking between panels
  • Solid aluminum die-cast construction makes these panels durable for the touring/rental market
  • Magnetic LED modules make replacing them fast and painless in the field or on the repair bench
  • Tri-color (RGB), full black body LEDs provide the highest in class contrast and black levels
  • Computer guided CNC cutting provides ultimate precision for seamless modular connections
  • Works with VIP Driver and VIP Signal Distributor
  • Use with the X-series Rig Bar to hang the panels, or with the M12 mounting points on the back of each panel
  • IP65 for temporary outdoor/wet use

Optical

  • Light Source: 5,184 LEDs (tri-color RGB) SMD 2623, 50,000 hours life expectancy
  • Color Wavelength: red (625 nm), green (525 nm), blue (470 nm)
  • Viewing Angle: 130°
  • Illuminance: 5,600 NITS
  • Pixels: 72 x 72
  • Pixel Pitch: 6.9 mm
  • Pixel Density: 20,736/m2
  • Contrast Ratio: 17,447:1
  • Display Refresh Rate: 1,920 Hz; 3,120 Hz available

Construction/Physical

  • Dimensions: 19.7 x 3.27 x 20.35 in (500 x 83 x 517 mm)
  • Weight: 21.2 lb (9.62 kg)
  • Threaded Bolt: M12
  • Exterior Color: Black
  • Housing Material: Aluminum die-cast
  • Transparency: 8%

Connections

  • Power Connection: Edison (Local) plug to Seetronic Powerkon IP65
  • Power Input: Seetronic Powerkon IP65
  • Power Output: Seetronic Powerkon IP65
  • Data Connectors: Seetronic Etherkon IP65
  • Cable Length (signal extension): 2.46 ft (0.75 m)
  • Cable Length (power): 6 ft (1.83 m)
  • Cable Length (power extension): 2.46 ft (0.75 m)

Control

  • Control Protocol: LINSN
  • Maximum Panels/VIP Driver: 120

Electrical

  • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power Linking: 17 units @ 120 V; 28 units @ 208 V; 29 units @ 230 V
  • Power and Current: 127 W, 1.05 A @ 120 V, 60 Hz
  • Power and Current: 135 W, 0.65 A @ 208 V, 60 Hz
  • Power and Current: 135 W, 0.63 A @ 230 V, 50 Hz

Certifications/Qualifications

  • CE, EMC, MET
  • IP Rating: IP65, temporary outdoor/wet use
  • Thermal Dissipation (Typical): 190 BTU per hour
  • Thermal Dissipation (Design Limit): 470 BTU per hour
  • Ambient Operating Temperature: -4 °F to 122 °F (-20 °C to 50 °C)

What’s Included

  • PVP X6IP
  • Seetronic Powerkon IP65 power cord
  • Seetronic Etherkon IP65 signal linking cord
  • Warranty Card
  • Quick Reference Guide or User Manual
